Eternal Hydraulic Parker PV Series Hydraulic Piston Pump
Parker Denison PV Series is a Pressure Compensated, Variable Volume Hydraulic Piston Pump High Strength Cast-Iron Housing.
TECHNICAL DATA
| Pump Model | Displacement cc/rev (ln3/rev) | Pump Delivery @ 21 bar (300 PSI) in LPM (GPM) | 1 Approx. Noise Levels dB(A) @ Full Flow 1800 RPM (1200 RPM) | Input Power At 1800 RPM, Max. Displacement & 248 bar (3600 PSI) | Operating Speed (RPM) (Maximum) | Pressure bar (PSI) Continuous (Maximum) | ||||||
| 34 bar (500 PSI) | 69 bar (1000 PSI) | 138 bar 2000 PSI) | 207 bar 3000 PSI) | 248 bar (3600 PSI) | ||||||||
| 1200 RPM | 1800 RPM | |||||||||||
| PV6 | 16 | (-98) | 19.7 (5.2) | 29.5 (7.8) | 53 (47) | 55 (50) | 59 (54) | 62 (56) | 65 (59) | 13.1 kw (17.5 hp) | 3000 | 248 (3600) |
| PV10 | 23 | (1.4) | 28.0 (7.4) | 42.0 (11.1) | 61 (57) | 64 (59) | 67 (63) | 69 (65) | 70 (65) | 19.7 kw (26.5 hp) | 3000 | 248 (3600) |
| PV15 | 33 | (2.0) | 39.4 (10.4) | 59.0 (15.6) | 64(59) | 66 (59) | 68 (62) | 70 (64) | 71 (65) | 27.2 kw (36.5 hp) | 3000 | 248 (3600) |
| PV20 | 41 | (2.5) | 49.2 (13.0) | 73.8 (19.5) | 68 (60) | 70 (61) | 73 (65) | 74 (67) | 75 (69) | 33.2 kw (44.5 hp) | 2800 | 248 (3600) |
Controls
• Pressure Compensation
• Load Sensing
• Horsepower Limiting
• Horsepower and Load Sensing
• Remote Pressure Compensation
• Adjustable Maximum Volume Stop
Features of Denison PV Hydraulic Pump
PV6
- High Strength Cast-Iron Housing for Reliability and Quiet Operation
- Vickers Porting Interchange
- Optional Inlet/Outlet Locations for Ease of Installation
- Replaceable Bronze Port Plate
- Replaceable Piston Slipper Plate
- Thru-Shaft Capability SAE A Pilots Offered
- Low Noise Levels
- Fast Response Times
PV10/15
- High Strength Cast-Iron Housing for Reliability and Quiet Operation
- Vickers Porting Interchange
- Optional Inlet/Outlet Locations for Ease of Installation
- Replaceable Bronze Port Plate
- Replaceable Piston Slipper Plate
- Thru-Shaft Capability SAE A and B Pilots Offered
- Low Noise Levels
- Fast Response Times
PV20
- High Strength Cast-Iron Housing for Reliability and Quiet Operation
- Vickers Porting Interchange
- Optional Inlet/Outlet Locations for Ease of Installation
- Replaceable Bronze Port Plate
- Replaceable Piston Slipper Plate
- Thru-Shaft Capability SAE BB, A, B or C Pilots
- Low Noise Levels
- Fast Response Times
Related Parker Piston Pump
F11 /F12 Series Piston Motor /Pump
Parker Gold Cup Series Piston Pump & Motor
Parker Series PVplus Hydraulic Piston Pump
Parker PVP Series Hydraulic Piston Pump
Advantages of Eternal Product
- Completely interchangeable with origina
- Very competitive price
- 1 year of warranty
- Short delivery time
